CR Product’s Automotive Typical Applications

Mild Steel
( 270D,270E,270F)

Skin Panel and Inner Panel
IF- High Strength Steel
( IFHSS 340)

Skin Panel and Inner Panel
(C-MN /HSLA)High Strength Steel (340LA,380LA, CR440)

Inner Panel - Body Structure
Advanced High Strength Steel (CQ590,DP590, DP780)

Inner Panels – Body

CRCA Steel Products ( Through CAPL Technology )

SL No.	JIS/JFS Standard	Tensile Strength (Mpa min)	Thickness Range	Width Range Max	Skin Application	Inner Application
1	JSC 270 C	270 min	0.4 to 2.3mm	1550mm
2	JSC 270 C	270 min	0.5 to 2.3mm	1550mm
3	JSC 270 D	270 min	0.55 to 2.3mm	1680mm
4	JSC 270 E	270 min	0.55 to 2.3mm	1680mm
5	JSC 270 F	270 min	0.55 to 2.3mm	1680mm
6	JSC 340 P	340 min	0.6 to 2.3mm	1510mm
7	BH 220	340 Min	0.6 to 2.3mm	1440mm
8	JSC 440 W	440 min	0.8 to 2.3mm	1550mm
9	HSLA	410 min	0.8 to 2.3mm	1510mm
10	HSLA	450 min	0.8 to 2.3mm	1510mm
11	JSC 590 R	590 min	0.6 to 2.3mm	1510mm
12	JSC 590 Y	590 min	0.6 to 2.3mm	1510mm
13	JSC 780 Y	780 min	0.8 to 2.3mm	1500mm
